Technical specification
Pipe OD | 75mm – 360mm (3”- 14”) |
---|---|
Max. wall thickness | 12mm (0.5") steel / 110V, 20mm (0.8”) steel / 230V, 45mm (2”) plastic |
Pipe material | Acid-resistant steel, Cast iron, Copper, Multi-layered materials, Plastic, Stainless steel, Steel |
Voltage / Power | 230V / 2500W |
Voltage / Current | 110V, 120V / 15A |
No-Load speed | I=1900 r/min, II=2885 r/min |
Blade diameter | 165mm (6.50”) |
Mounting bore | 62mm (2.44”) |
Weight | 17,5 kg (38,6 lbs) |
Electronical unit | Blade speed preselection, automatic fuse, soft start, torque control |
Speed preselection | I = Stainless steel and acid-resistant steel, II = all other materials |
Loading capacity of supports | 465 kg, 1025 lb (3 supports) |
